Differential
Pressure Transducer/Transmitter Models 115, 215, 315
Features:
• Rugged, All Welded, Totally Encapsulated Electronics
• Leakproof. No O-Ring Construction
• Small Size
• All Stainless Steel Wetted Parts
• Many East-To-Order Options
• Base Pressure to 10,000 psi (With Option HM)
Pressure Ranges:
• From 30 to 5,000 psid
• From 2 to 300 bar
• Bi-Directional Available
• Model 115: Output @ 70°F: 3 mV/V ±2% FSO
• Model 215: Output @ 70°F: 0 ±5 VDC ±2% FSO
• Model 315: Output @ 70°F: 4-20 mA ±2% FSO
Differential Pressure Transducer/Transmitter
GP:50 Models 115, 215, 315
|
