Non-Contact
Position Measurement Systems Shortform
Advanced
Technology. Kaman's sensors are based on eddy
current technology, providing Non Contact Position
Measurement Systems that are very stable and repeatable,
ideal for metal targets, unaffected by humidity,
dust and other contaminants and resistant to harsh
environments.
|
|
KD2300
Multi-Purpose Displacement Measuring System
Kaman
Instrumentation’s Multi-VIT Displacement
Measuring System, the KD-2300, is a noncontact
linear proximity measuring system.
This
easy-to-use system makes high precision static
and dynamic measurements for product design, fabrication,
process control, and inspection of metal objects.
It replaces LVDTs, air gauges, dial indicators,
and micrometers.
|
|
|
|
|
|
|
|
High
Precision Eddy Current Measuring System Kuda Series
Kuda
is a High-Precision Eddy Current Measuring System.
Microprocessor-based sensing systems offer many
benefits over analog systems, especially in applications
that have many variables. Kaman’s
Kuda Eddy Current Measuring System, a smart digital
system, has the ability to implement many control
features that in the past required a PLC or other
microprocessor-based controller.
|
|
KD2440
Non Contact Proximity Measuring System
Kaman
Instrumentation ’s displacement measuring
system Model KD-2440 is a Non Contact Proximity
Measuring System. This low-cost, easy-to-use system
makes precision static and dynamic measurements
of metal targets, and thickness measurements
of nonconductive material backed by metal. Its
switching output will track RPM measurement to
10 KHz.
|
|
|
|
|
DIT5200
Differential Impedance Transducer
Features:
• True differential for common mode rejection
at an economical price
• High precision eddy current balanced bridge
technology
• Capable of subnanometer resolution
• Thermal stability ±.03% FS/°C, at null ±.005%
FS/°C
|
|
|
|
|
|
|
|
Non-Contact High-Precision Proximity Measuring System Kaman KD2446
The
KD-2446 system consists of two subassemblies: the sensor,
with integral cable, and the signal conditioning or electronics
module. The KD-2446 electronics is housed in DIN rail
mount enclosure with terminal connections for +12 Vdc
to +24 Vdc input power and the variable voltage and switched
outputs.
|
|
