Stress
Analysis Data System 5000
|
 The
Measurements Group revolutionized strain measurement
in 1981 with the introduction of System 4000 Stress
Analysis Data System, a complete hardware/software
approach to data acquisition, reduction and presentation
for strain gauges and related sensors for stress
analysis testing. Since that time, more than fifty-thousand
channels have been used around the world in university
laboratories, major research facilities, and virtually
every industry.
Stress Analysis Data System System 5000 takes
this concept into the next generation of data
acquisition by using new developments in hardware
and software to add features not previously possible.
Stress Analysis Data System System 5000 Principal
Features:
• Inputs accepted from strain gauges, strain gauge
based transducers,LVDT's, thermocouples, and sensors
with high-level outputs.
• Stable, accurate, low-noise signal conditioning.
• From 5 to 1200 input channels, can be configured
as needed at any time.
• Scanning and recording intervals as short as
0.1 second for up to 1200 inputs.
• Built-in bridge completion for 120, 350 and
1000 Ohm strain gauges.
• Available with ISA (Windows 3.1 or 95) and/or
PCMCIA (Windows 95) hardware interfaces.
Stress
Analysis Data System 5000
|
|
