Transducer
Class Strain Gauges
Transducer-Class Strain Gauges are a select group of gauge
patterns designed specifically for transducer applications.
The main objective is optimum gauge performance at lower
cost in high-volume production quantities.
|
|
|
|
|
M-Line
Strain Gauge Accessories
Strain
Gauge Accessories Vishay M-Line have been developed and
selected for effectiveness, ease-of-use in making strain
gauge installations, reliability and consistency of properties.
|
|
Basic
Strain Gauge (Gage) Instrumentation
Basic Strain Gage Instrumentation requirements call for
stability, accuracy and high resolution when making measurements
under static loading conditions, and particularly where
measurements are to be taken over long periods of time.
|
|
|
|
|
Stress
Analysis Data System 6000
The new Stress Analysis Data System 6000 is a powerful
hardware / software approach for Data Acquisition, Reduction
and Presentation for Strain Gauges and related Sensors
for Stress Analysis.
|
|
|
|
|
StrainSmart
Software for Stress Analysis Testing
StrainSmart is a ready-to-use, Windows-based software
system for acquiring, reducing, presenting and storing
measurement data from strain gauges, strain-gauge-based
transducers, thermocouples, temperature sensors, LVDT's,
potentiometers, piezoelectric sensors and other commonly
used transducers.
|
|
Model
2100 System Signal Conditioners
Signal
Conditioning Amplifier Vishay 2100, amplifiers accept
low-level signals, and conditions and amplifies them into
high-level outputs suitable for multiple channel simultaneous
dynamic recording.
|
|
|
|
|
Model
2300 Signal Conditioning Amplifier System
A versatile, multi-channel, dynamic instrumentation system
that generates high-level signals from strain gauges (or
strain gauge based transducers) for display or recording
of data on external equipment.
|
|
Model
A2 Signal Conditioner Amplifier System
The A2 is an analog signal conditioner and amplifier system for strain gauges, strain-gauges based transducers,
thermocouples and various other sensors with high-level signals.
|
|
Model
3800 Wide Range Strain Indicators
The Model 3800 Wide Range Strain Indicators are versatile,
high precision laboratory type instruments designed for
use with strain gauges and strain gauged based transducers.
|
|
Model
1550A Strain Indicator Calibrator
Strain
Indicator Calibrator Vishay Model 1550A is atrue Wheatstone-bridge
simulator, the 1550A Strain Indicator Calibrator presents
known and repeatable resistance changes to the input of
the indicator.
|
|
Model
P3 Strain Indicator & Recorder
The
P3 Strain Indicator is a portable, battery- operated instrument
capable of simultaneously accepting four inputs from quarter-,
half-, and full-bridge strain-gauge circuits, including
strain-gauge-based transducers.
|
|
Model
1300 Gauge Installation Tester
Strain
Gage Installation Tester Vishay Model 1300 is used to
verify the electrical quality of an installed strain gage,
as well as the complete gage installation, including leadwires.
|
|
|
|
|
|
|
|
Model
1601 LVDT Adapter & Model 1611 Thermocouple Adapter
Linear
Variable Differential Transformer Adapter (LVDT) outputs
can now be measured/displayed/recorded with standard strain
gauge instrumentation.
Thermocouple
Adapter Model 1611 adds a new dimension to strain gauge
instrumentation by allowing thermocouple outputs to be
monitored with standard strain-measuring instruments.
|
|
PhotoStress
PhotoStress
is a full-field technique used in Stress Analysis Testing.
Initial observation of a photoelastic pattern provides
quick qualitative analysis of the overall stress distribution.,
and then accurate quantitative data at any selected point(s)
is easily obtained using straightforward measurement techniques
and modern optical instrumentation.
|
|
|
|
|
Linear
Displacement Sensor
Micro-Measurements
Linear Displacement Sensor uses a fully active 350 Ohm
strain-gauge bridge to sense spindle displacement, giving
infinite resolution and excellent linearity.
|
|
